دستگاه اسپکتروفتومتر Visible مدل DR6000 نمایندگی HACH

مشخصات فنی طیف سنج HACH DR6000 UV-VIS

(Data Logger:5000 data points (result, date, time, sample-ID, user-ID
Dimensions (H x W x D):215 mm x 500 mm x 460 mm
Display:TFT 7 inch WVGA color touch
Enclosure Rating:IP20 with closed lid
(Includes:1 x Power Cord (US, EU
۱x Universal-Adapter
۱x Dust Cover
Matched pair of 1 inch glass sample cells
(Printed multilingual basic user manaul (en, es, fr, ja, ko, pt, zh
Interfaces:USB type A (2), USB type B, Ethernet, RFID module
Manual Languages:en, es, fr, ja, ko, pt, zh
(Operating Conditions:10 – 40 °C, max. 80% relative humidity (non-condensing
(Operating Mode:Transmittance (%), absorbance and concentration (wavelength, time
Optical System:Reference beam, spectral
Photometric Accuracy:5 mAbs @ 0.0 – 0.5 Abs
<1% @ 0.5 – 2.0 Abs @ 546 nm
Photometric Linearity:0.005 – 2 Abs
≤ ۰٫۰۱ at > 2 Abs with neutral glass at 546 nm
Photometric Measuring Range:± ۳ Abs
Power Requirements:100 – 240 V; 50/60 Hz
Preprogrammed Methods:> 240
Sample Cell Compatibility:Rectangular: 10, 20, 30, 50 mm, 1 inch; round: 13 mm, 16 mm, 1 inch

Optional 100 mm rectangular cell with additional adapter
(Scanning Speed:900 nm/min (in 1 nm steps
Specific Technology:RFID for easy method update, sample ID and Certificate of Analysis
Spectral Bandwidth:2 nm
(Storage Conditions:-25 to 60 °C / max. 80% relative humidity (non-condensing0
Stray Light:KI-solution at 220 nm < 3.3 Abs/ < 0.05%
User Interface Languages:bg, cn, cz, da, en, es, fr, gr, hr, hu, it, jp, kr, nl, pl, pt, ro, ru, sl, sl, sv, tr
User Programs:200
Warranty:1 year
Wavelength Accuracy:± ۱ nm
Wavelength Range:190 – 1100 nm
Wavelength Reproducibility:< 0.1 nm
Wavelength Resolution:0.1 nm
Wavelength Selection:Automatic, based on method selection
Weight:11 kg
