unico SQ-4802 Spectrophotometer

UNICO SQ-4802 is a Double beam design. It is a stand-alone model with 1.8 nm fixed bandwidth and has all the features that SpectroQuest line offers in a stand-alone unit. The two detectors are measuring sample and reference respectively and simultaneously for optimizing measurement accuracy. It provides excellent performance for measurements in the range of 190nm to 1100nm. It is suitable for pharmaceutical, biochemical and clinical lab applications as well as routine applications such as quantitative analyses, kinetics, spectrum scanning, multiple components and DNA/Protein. Optional software make this instrument versatile.

UNICO SQ SERIES DOUBLE-BEAM SCANNING SPECTROPHOTOMETER
STANDARD FUNCTIONS INCLUDE SCANNING KINETICS STANDARD CURVE AND MORE
EXPANDED DIGITAL INTERFACE WITH INTERNAL MEMORY AND AUTO SYSTEM CHECK
WAVELENGTH RANGE 190-1100NM
۱٫۸NM SPECTRAL BANDWIDTH
۲ SINGLE PLACE HOLDERS FOR 10 MM SQUARE CUVETTES( REFERENCE AND TEST)
USB PORT FOR OPTIONAL SOFTWARE
INCLUDED ARE 2PCS OF 10MM SQUARE QUARTZ CUVETTES; 4 PCS OF 10MM SQUARE GLASS CUVETTES; DUST COVER; USER MANUAL

Wavelength Range: 190 – 1100 nm
Spectral Bandwidth: 1.8 nm
Monochromator: Double beam Littrow type, grating 1200 lines/mm
Wavelength Accuracy: ±۰٫۳ nm
Wavelength Repeatability: ±۰٫۲ nm
Wavelength Calibration: automatic at start
Light Source: Tungsten Halogen/Deuterium Lamp
Detector: Solid Silicon Photodiode
Photometric Readout: 1/4 VGA 320X240 pixels backlit LCD
Photometric Range: 0 – 200%T -0.3 – 3.0A 0 – 9999C
Photometric Accuracy: ±۰٫۳%T
Zero Drift
Baseline Flatness: ±۰٫۰۰۴A
Stability: 0.001A/h at 500 nm
Stray Light
Scanning Speed: Hi, Med., Low. Max. 1000 nm/min
Standard Sample Holder: Single Cell Holder
Analogue/Digital Output: Digital, RS232 Serial, Centronics Parallel
Dimensions: 620(L) x 400(W) x 280(H) mm
Weight: 24 kg / 53lbs
Shipping Dimensions: 720(L) x 525(W) x 370(H) mm
Shipping Weight: 28 kg / 62 lbs
Power Requirements: 110V/60Hz switchable
Humidity Range: less than 85%
